00044674 burkert订货号0330-3/2常闭型电磁阀-DN3-NBR密封-黄铜阀体-G1/4"-024/50-08
来源:http://burkertfluid.cn2018-3-4 9:46:17

Description

Identnumber                                             00044674

Key                                                          0330-C-03,0-BB-MS-GM82-024/50-08   *  JF01+LF02

BSTALT

Description                                              3/2-way-solenoid valve; direct acting



Type (TYP)                                               0330 - 0330

Circuit function (WW)                                C - 3/2-ways; normally closed; o utput A

balanced

Orifice size (DN)                                       03,0 - 3,0mm (1/8")

Seal material (DWST)                                BB - NBR

Body material (WKST)                               MS - brass

Port connection (LTA)                               GM82 - G1/4 threaded port

Voltage (SP)                                            024 - 24 volts

Frequency (FR)                                         50 - 50 Hz

Power consumption (LEIS)                        08 - 8 watt

Variable Code 1 (VAR1)                            JF01 - standard cable plug

Variable Code 2 (VAR2)                            LF02 - electr. feedback signalle r 1060-10S

Substitute-ID

ConformitySign                                        CEX0

Delivery Time                                           28 Calender Days



Technical Data

PRESS. MAX. (BAR) (DRMAXBAR)                                                      10

PRESS MAX. (PSI) (DRMAXPSI)                                                          145

PRESS. MIN. (BAR) (DRMINBAR)                                                         0

PRESS. MIN (PSI) (DRMINPSI)                                                             0

REQUIRED PILOT PRESS.F.MAX.FLUID PRESS.(BAR) (STDRERFBAR)

REQUIRED PILOT PRESS.F.MAX.FLUID PRESS.(PSI) (STDRERFPSI)

PILOT PRESS. MAX (BAR) (STDRMAXBAR)

PILOT PRESS MAX. (PSI) (STDRMAXPSI)

PILOT PRESS. MIN. (BAR) (STDRMINBAR)

PILOT PRESS. MIN. (PSI) (STDRMINPSI)

KV-VALUE (M*3/H) (KV)                                                                       0.18

QNN-VALUE (L/MIN) (QNN)                                                                   195

WEIGHT (KG) (MASSE)                                                                        0.40

FLUID TEMP. MAX. (DEGREE C) (MEDTEMPMAX)                              +80

FLUID TEMP. MIN. (DEGREE C) (MEDTEMPMIN)                                 0

AMB. TEMP. MAX. (DEGREE C) (UMGTEMPMAX)                               +55

AMB. TEMP. MIN. (DEGREE C) (UMGTEMPMIN)

PRESSURE (DRUCK)

SWITCH-ON TIME(%) (ESDAUER)                                                        100

OPENING TIME MAX. (MS) (TOEFFMAX)                                              15

OPENING TIME MIN. (MS) (TOEFFMIN)                                                 8

CYCLING RATE (1/MIN) (SH)

CLOSING TIME MAX. (MS) (TSCHLMAX)                                              15

CLOSING TIME MIN. (MS) (TSCHLMIN)                                                 8



ID: 00044674                0330-C-03,0-BB-MS-GM82-024/50-08   *  JF01+LF02

1            00600318      1               Housing G 1/4                                                              20001208             0314-0001-000-V0

2            00011958      1               Blanking plate                                                              20001208             0330-0062-000-00

3            00010143      1               Compression spring WW A, C, E, F                               20001208             0314-0056-000-00

4            00623601      1               Taststift kpl.                                                                 20001208             0314-1070-000-00

5            00010138      1               Compression spring                                                     20001208             0314-0054-001-00

6            00011669      1               COMPRESSION SPRING                                              20001208             0314-0055-007-00

7            00011691      1               Diaphragm  B                                                              20001208             0330-0095-001-00

8            00609485      1               SPULE  24/50 GEB.  ( STEMPEL B )                           20001208             0330-4250-102-00

9            00610649      1               Anchor nickel plates 1 altern. current                         20001208             0330-2158-004-00

10          00100399      4               Cheesehead screw  BM 4 x 55 4.8 A 2 K                       20001208             0006-7491

11          00008376      1               Plug connection 28 mm        20001208      2508BG01

14          00100107      1               Shaft lock 3,2 D bronze                                                20001208             0006-7973

15          00637226      1               Label  38,1 x 19,05                                                      20001208             0480-0233-000-00

25          00623002      1               SITZ KPL3,0/B f DN3,0 AC    MS M6                       20001208             0314-1008-011-00

26          00623002      1               SITZ KPL3,0/B f DN3,0 AC    MS M6                       20001208             0314-1008-011-00

30          00011853      1               Plunger                                                                        20001208             0330-0071-000-00

31          00612978      1               Electr. feedback                                                           20001208             1060-G1-00612978

36          00636912      1               Klebeschild bedruckt WWC                                           20001208             0330-0182-003-00
